add origami inference examples

.gitattributes

@@ -34,3 +34,7 @@ saved_model/**/* filter=lfs diff=lfs merge=lfs -text
 *.zst filter=lfs diff=lfs merge=lfs -text
 *tfevents* filter=lfs diff=lfs merge=lfs -text
 tokenizer.json filter=lfs diff=lfs merge=lfs -text
+assets/sample_head_left.png filter=lfs diff=lfs merge=lfs -text
+assets/sample_head_right.png filter=lfs diff=lfs merge=lfs -text
+assets/sample_wrist_left.png filter=lfs diff=lfs merge=lfs -text
+assets/sample_wrist_right.png filter=lfs diff=lfs merge=lfs -text

README.md

@@ -19,55 +19,151 @@ The checkpoint uses continuous action inference. Dataset normalization metadata
 pip install torch transformers pillow numpy huggingface_hub
 ```

-## Inputs
+## Sample Input

-The model expects five RGB images in this order:
+This sample comes from `season_POC22032_2026_05_14_19_21_01_train`, episode 0, frame 1000. The task annotation is `north ces task`.

-1. `observation.images.head_left`
-2. `observation.images.head_right`
-3. `observation.images.wrist_left`
-4. `observation.images.wrist_right`
-5. `observation.images.tactile_deform`
+The camera order for this checkpoint is head-left, head-right, wrist-left, wrist-right, tactile-deform.

-The robot state is a single concatenated vector:
+| Head Left | Head Right | Wrist Left |
+| --- | --- | --- |
+| ![Sample head-left RGB](assets/sample_head_left.png) | ![Sample head-right RGB](assets/sample_head_right.png) | ![Sample wrist-left RGB](assets/sample_wrist_left.png) |
+
+| Wrist Right | Tactile Deform |
+| --- | --- |
+| ![Sample wrist-right RGB](assets/sample_wrist_right.png) | ![Sample tactile-deform RGB](assets/sample_tactile_deform.png) |
+
+Origami training concatenates `observation.state` and `observation.tactile` before passing the state into the model:

 ```python
-state = np.concatenate(
+from huggingface_hub import hf_hub_download
+from PIL import Image
+import numpy as np
+
+repo_id = "hqfang/molmoact2-origami"
+
+head_left = Image.open(
+    hf_hub_download(repo_id, "assets/sample_head_left.png")
+).convert("RGB")
+head_right = Image.open(
+    hf_hub_download(repo_id, "assets/sample_head_right.png")
+).convert("RGB")
+wrist_left = Image.open(
+    hf_hub_download(repo_id, "assets/sample_wrist_left.png")
+).convert("RGB")
+wrist_right = Image.open(
+    hf_hub_download(repo_id, "assets/sample_wrist_right.png")
+).convert("RGB")
+tactile_deform = Image.open(
+    hf_hub_download(repo_id, "assets/sample_tactile_deform.png")
+).convert("RGB")
+
+task = "north ces task"
+
+observation_state = np.array(
+    [
+        1.0490574, -0.5202958, -0.081635103, 1.1234368, -0.16848825,
+        -0.17774895, 0.32093349, 1.1820049, -0.015503892, -0.22338045,
+        -0.054003395, 0.19747166, 1.1392729, 0.0037120704, 0.20939526,
+        0.18640123, 0.80856121, 0.054220561, 0.86714411, 0.20072246,
+        0.52739459, 0.12671313, 1.1206218, 0.2093568, 0.054587767,
+        0.39636838, 0.13089132, 0.73561513, 0.62315375, 1.0669012,
+        -0.50566864, -0.10724012, 1.0205883, -0.38752872, -0.059374165,
+        0.40863451, 1.2579446, 0.13169624, -0.004245867, -0.11287238,
+        0.34268361, 1.2139554, -0.014323864, 0.22620225, 0.19668068,
+        1.1637404, -0.026463741, 0.48477855, 0.29940978, 0.73284894,
+        0.10251313, 0.79543447, 0.3646262, 0.013743274, 1.4660013,
+        0.25514615, 1.5681823, 1.3074577, 0.56268334, -1.106863,
+        0.72058749, 0.035089809, 0.054360446, -0.055702679, -0.62337142,
+    ],
+    dtype=np.float32,
+)
+observation_tactile = np.array(
     [
-        observation_state,    # observation.state, 65 dims
-        observation_tactile,  # observation.tactile, 60 dims
+        0.07043457, 0.44433594, -0.20898438, 0.0043830872, 0.0062179565,
+        -0.00070285797, 0.39355469, -0.0039825439, 0.11804199, -0.0015954971,
+        0.0025863647, 0.0075416565, -0.0035018921, 0.0027160645, -0.0034484863,
+        6.6518784e-05, 0.00020933151, -0.00014781952, -0.0017547607, -0.005027771,
+        -0.010017395, 0.00012350082, -0.00011891127, -4.1007996e-05, 0.014160156,
+        -0.0014038086, -0.0091247559, 0.00027275085, 7.8439713e-05, 0.00023460388,
+        -3.5722656, 6.28125, 9.078125, -0.13024902, 0.01159668,
+        -0.057006836, -9.796875, 0.63378906, 7.921875, -0.13171387,
+        0.013977051, -0.1862793, -0.00080108643, -0.0090332031, -0.00062561035,
+        -2.5749207e-05, -0.00018501282, 3.4332275e-05, 0.00028610229, 0.0017700195,
+        0.0065460205, -0.00017929077, -9.5367432e-06, 2.2411346e-05, -0.0016269684,
+        0.00019073486, -0.0073242188, 0.00037384033, 3.3140182e-05, -0.00012779236,
     ],
-    axis=-1,
-).astype(np.float32)
+    dtype=np.float32,
+)
+robot_state = np.concatenate([observation_state, observation_tactile], axis=-1).astype(np.float32)
 ```

-Do not pass `observation.state.joint_torque`, `observation.state.tcp`, or `observation.images.tactile_raw` unless you fine-tune a separate checkpoint that was trained with those inputs.
+`observation_state` has 65 dimensions and `observation_tactile` has 60 dimensions, so `robot_state` has 125 dimensions. Do not pass `observation.state.joint_torque`, `observation.state.tcp`, or `observation.images.tactile_raw` unless you fine-tune a separate checkpoint that was trained with those inputs.

-The model predicts 30 actions, each with 65 dimensions.
-
-## Continuous Action Inference
+## Continuous Actions

 ```python
 import numpy as np
 import torch
+from huggingface_hub import hf_hub_download
 from PIL import Image
 from transformers import AutoModelForImageTextToText, AutoProcessor

 repo_id = "hqfang/molmoact2-origami"

-# Replace these with the current Origami observation images.
-head_left = Image.open("head_left.png").convert("RGB")
-head_right = Image.open("head_right.png").convert("RGB")
-wrist_left = Image.open("wrist_left.png").convert("RGB")
-wrist_right = Image.open("wrist_right.png").convert("RGB")
-tactile_deform = Image.open("tactile_deform.png").convert("RGB")
-
-# Origami training concatenated observation.state and observation.tactile.
-observation_state = np.asarray([...], dtype=np.float32)    # shape: (65,)
-observation_tactile = np.asarray([...], dtype=np.float32)  # shape: (60,)
-robot_state = np.concatenate([observation_state, observation_tactile], axis=-1).astype(np.float32)
+head_left = Image.open(
+    hf_hub_download(repo_id, "assets/sample_head_left.png")
+).convert("RGB")
+head_right = Image.open(
+    hf_hub_download(repo_id, "assets/sample_head_right.png")
+).convert("RGB")
+wrist_left = Image.open(
+    hf_hub_download(repo_id, "assets/sample_wrist_left.png")
+).convert("RGB")
+wrist_right = Image.open(
+    hf_hub_download(repo_id, "assets/sample_wrist_right.png")
+).convert("RGB")
+tactile_deform = Image.open(
+    hf_hub_download(repo_id, "assets/sample_tactile_deform.png")
+).convert("RGB")

 task = "north ces task"
+observation_state = np.array(
+    [
+        1.0490574, -0.5202958, -0.081635103, 1.1234368, -0.16848825,
+        -0.17774895, 0.32093349, 1.1820049, -0.015503892, -0.22338045,
+        -0.054003395, 0.19747166, 1.1392729, 0.0037120704, 0.20939526,
+        0.18640123, 0.80856121, 0.054220561, 0.86714411, 0.20072246,
+        0.52739459, 0.12671313, 1.1206218, 0.2093568, 0.054587767,
+        0.39636838, 0.13089132, 0.73561513, 0.62315375, 1.0669012,
+        -0.50566864, -0.10724012, 1.0205883, -0.38752872, -0.059374165,
+        0.40863451, 1.2579446, 0.13169624, -0.004245867, -0.11287238,
+        0.34268361, 1.2139554, -0.014323864, 0.22620225, 0.19668068,
+        1.1637404, -0.026463741, 0.48477855, 0.29940978, 0.73284894,
+        0.10251313, 0.79543447, 0.3646262, 0.013743274, 1.4660013,
+        0.25514615, 1.5681823, 1.3074577, 0.56268334, -1.106863,
+        0.72058749, 0.035089809, 0.054360446, -0.055702679, -0.62337142,
+    ],
+    dtype=np.float32,
+)
+observation_tactile = np.array(
+    [
+        0.07043457, 0.44433594, -0.20898438, 0.0043830872, 0.0062179565,
+        -0.00070285797, 0.39355469, -0.0039825439, 0.11804199, -0.0015954971,
+        0.0025863647, 0.0075416565, -0.0035018921, 0.0027160645, -0.0034484863,
+        6.6518784e-05, 0.00020933151, -0.00014781952, -0.0017547607, -0.005027771,
+        -0.010017395, 0.00012350082, -0.00011891127, -4.1007996e-05, 0.014160156,
+        -0.0014038086, -0.0091247559, 0.00027275085, 7.8439713e-05, 0.00023460388,
+        -3.5722656, 6.28125, 9.078125, -0.13024902, 0.01159668,
+        -0.057006836, -9.796875, 0.63378906, 7.921875, -0.13171387,
+        0.013977051, -0.1862793, -0.00080108643, -0.0090332031, -0.00062561035,
+        -2.5749207e-05, -0.00018501282, 3.4332275e-05, 0.00028610229, 0.0017700195,
+        0.0065460205, -0.00017929077, -9.5367432e-06, 2.2411346e-05, -0.0016269684,
+        0.00019073486, -0.0073242188, 0.00037384033, 3.3140182e-05, -0.00012779236,
+    ],
+    dtype=np.float32,
+)
+robot_state = np.concatenate([observation_state, observation_tactile], axis=-1).astype(np.float32)

 processor = AutoProcessor.from_pretrained(repo_id, trust_remote_code=True)
 model = AutoModelForImageTextToText.from_pretrained(
@@ -111,7 +207,9 @@ with torch.inference_mode(), torch.autocast("cuda", dtype=torch.bfloat16):
     out = model.predict_action(...)
 ```

-`normalize_language=True` is the default. It lowercases the task string and removes trailing sentence punctuation to match training preprocessing. `enable_cuda_graph=True` is also the default; the first few calls can be slow while CUDA graphs are warmed up and captured.
+`normalize_language=True` is the default. It lowercases the task string and removes trailing sentence punctuation to match training preprocessing. `enable_cuda_graph=True` is also the default; the first few calls can be slow while CUDA graphs are warmed up and captured. `num_steps` controls the continuous flow solver.
+
+Depth reasoning is disabled for this checkpoint. Calling `enable_depth_reasoning=True` will raise an error.

 ## Model and Hardware Safety
